CAS-GPS IVU BASIC SYSTEMS INSTALLATION MANUAL DOCU0085 Revision Q
Shovel Heading Testing
The second status icon indicates the communication
status to the node:
• Green indicates good.
• Yellow indicates warning, no message received
in the last 5 seconds.
• Red indicates error, no message received in the
last 5 minutes.
Pressing the button displays the primary and
secondary GPS information.
