Introduction
1.8 Symbol descriptions
The following symbols are displayed on the machine to provide pictorial information to the
user. The information and explanations are provided to avoid misinterpretation by the user.
The symbols have been chosen to provide important information to those involved with
operating, adjusting, maintaining, and repairing this machine.
Description
Lift the machine or machine parts only by means of these lifting points.
– see chapter 3.19 Lifting the machine on page 3-28
Location
On the rear chassis next to the lifting point
Description
Tie down points.
Location points designated for tie down of the machine during transport to prevent
movement during transport.
Location
In the ner of the dump bucket
Description
Loading indications for machine.
– see chapter Strapping down the machine on page 3-30
Location
On the engine cover
Description
Noise levels produced by the machine.
L
WA
= sound power level
Other information – see chapter 6.11 Noise levels on page 6-4
Location
On the engine cover
Description
This label indicates the maximum authorized angle of inclination for driving on slopes,
whatever the position of the machine.
Location 3001 Front Tip
On the dump bucket
Fig. 7: Eye hook label
Fig. 8: Label for points used for strapping down the
machine

KRRNRIFUDQH
.UDQKDNHQ
&URFKHWGHJUXH
%JHO
KDQGOH
(WULHU
+HEHEDQG
(OLQJXHHQUXEDQ
OLIWLQJEHOW
(LOOHWRQGHOHYDJH
VWRSH\H
+XE|VH
.QLFNVSHUUHHLQOHJHQ
IDVWHQDUWLFXODWLRQUHVLVWDQFH
$SSOLTXHUOHGLVSRVLWLIGHEORFDJHGHODUWLFXODWLRQ
Fig. 9: Label with indications for loading the machine

Fig. 10: Noise level label
Fig. 11: Driving on slopes Front Tip
