3-88
BA 50Z3/6003 en – Edition 4.3 * * 5003b340.fm
Operation
Directional v
alve
The directional valve switches from
ISO to SAE controls and vice versa.
☞
Tighten wing nut
J
after changing the control mode.
Caution!
No driving or working with the machine if wing nut
J
is malfunctioning.
☞
Immediately contact an authorized wo
rkshop to replace a malfunctioning
wing nut.
Fig. 179:
Directional valve
J
A
B
Position
Function
A
ISO controls
B
SAE controls
143
145
