Introduction
Meaning
Caution, danger of severe or fatal injuries.
Stay clear of the machine’s work range during operation.
Location
On either side of the boom.
Meaning
Caution, the safe load indicator must always be switched on during lifting gear applications.
Stay clear of the machine’s work range during operation.
Location
Beside the safe load indicator switch.
Meaning (up to serial no. AH01643)
General indication of danger
This label warns persons standing or working near the machine of an existing danger
within the area of increased danger around the machine.
Location
On either side of the boom
Meaning (up to serial no. AH01643)
Hydraulic oil tank under pressure.
– see Adding hydraulic oil on page 5-30
Location
On the hydraulic oil tank
Meaning (up to serial no. AH01643)
Press the boom and the stabilizer blade into the ground as you leave the machine, remove
the ignition key and place chocks on the left and right under the tracks – see chapter
Parking checklist on page 3-16.
Location
Cab roof lining.
Meaning (option 50Z3)
Remove the shatter protection if the machine is transported on an open platform.
Location
On the shatter protection at the upper left in driving direction.
Fig. 43: Safe load indicator
Fig. 45: Hydraulic oil tank under pressure
Fig. 46: Parking the machine correctly
Fig. 47: Removing the shatter protection
