Wacker Neuson 6003

BA 50Z3/6003 en – Edition 4.3 * 5003b320.fm 3-3
Operation
Pos.
Description For more information see page
1 Cover for hammer pedal
2 Hammer pedal......................................................................................................................................................................3-84
3 Left-hand control lever................................................................................................................................3-83, 3-87, 3-94, 3-94
4 Right-hand control lever..............................................................................................................................3-85, 3-87, 3-85, 3-85
5 Control lever base (left) .........................................................................................................................................................3-60
6 Control lever base (right)
7 Armrest (left)
8 Armrest (right)
9 Lever (horizontal seat adjustment)
..........................................................................................................................................3-38
10 Air vent (rear window, on the left)
11 Air vent (rear window, on the right)
12 Radio (option)
13 Seat (backrest adjustment)
....................................................................................................................................................3-38
14 Seat belt (lock) .....................................................................................................................................................................3-45
15 Cup holder
16 Document storage bin
17 Switch panel
..........................................................................................................................................................................3-6
18 Throttle................................................................................................................................................................................3-17
19 Fuse box................................................................................................................................................................................6-3
20 Preheating start switch ..........................................................................................................................................................3-17
21 Cigarette lighter
22 Round display element ............................................................................................................................................................................. 3-6
23 Drive pedal (left) ...................................................................................................................................................................3-24
24 Drive pedal (right) .................................................................................................................................................................3-24
25 Drive lever (left) ....................................................................................................................................................................3-24
26 Drive lever (right)..................................................................................................................................................................3-24
27 Stabilizer-blade lever/pedal....................................................................................................................................................3-28
28 Heating controls (from serial no. AD04651)............................................................................................................................................ 3-34
29 Coolant temperature indicator ................................................................................................................................................................ 3-13
