Wacker Neuson 8003 2 - 1.2 Machine overview

OM 75Z3/8003 US – Edition 4.0 * 7003b110.fm 1-3
Introduction
1.2 Machine overview
1 Working lights (option)
2 Boom mounted work light
3 Undercarriage
4 Stabilizer blade
5 Engine cover
6 Handrail
7 Fuel tank filler inlet
8 Exhaust pipe
9 Lifting/tying down point
10 Rotating beacon (option)
11 Auxiliary hydraulics
12 Tank cover
13 Door arrester
14 Door handle and lock
15 Counterweight (option)
