Rammer
Lifting and Transporting
Continued from the previous page.
If the rammer cannot be secured in the upright position,
a.Drain the fuel tank to prevent fuel from leaking from the cap (c).
b.
Lay the rammer down only as shown and tie it to the vehicle at points (a) and (b) .
Transporting
manually
Rollers (d) enable the rammer to be rolled from one location to another. Perform
the procedure below to transport the rammer manually.
1. Drain the fuel tank to prevent fuel from leaking from the cap.
2. Lay the rammer down as shown.
3. Raise the rammer by the lifting handle (b).
4. Roll the rammer forward or backward as needed.
a
d
c
b
wc_gr010406

Wacker Neuson BS50-2 Specifications

General

Engine Model	Wacker Neuson WM 80
Displacement	80 cm³
Percussion Rate	700 blows/min
Fuel Type	Gasoline/oil mixture
Fuel Tank Capacity	3.0 liters
Engine Output	1.8 kW
