5-2 BA D18 us* 1.1 * D18b500.fm
5 Operation
5.1 Steering system
The machine is steered with a steering wheel. The mechanical actuation
is transmitted to a travel cylinder. Steering is therefore not performed by
means of a steering axle, but with the steering joint.
Emergency steering features
The machine can still be steered if the engine or the pump unit breaks
down, however this requires more muscle strength. Take this into account
especially when towing the machine.
Function Machine movement
Steering wheel turned to
the left
Machine is steered to the left and turns left
Steering wheel turned to
the right
Machine is steered to the right and turns right
