Technical data 9
Values
DW60 standard DW60 3 m skip
1
1. Legislation in some countries requires a specific distance between the center of the steering wheel and the front edge of the machine. This distance is main-
tained with the optional 3 m skip.
DW90
mm (in) mm (in) mm (in)
A1 Height including rotating beacon 3350 (10'-12'') 3595 (11'-10'')
A2 Height without rotating beacon 3110 (10'-2'') 3355 (10'-10'')
A3 Height with lowered rollbar 2300 (91) 2545 (8'-4'')
A4 Height of lowered rollbar 2185 (86) 2430 (96)
B1 Length without maneuvering coupling 4835 (15'-10'') 4670 (15'-4'') 5085 (16'-8'')
B2 Length with maneuvering coupling 4935 (16'-2'') 4770 (15'-8'') 5185 (17'-0'')
B3 Length with lowered rollbar 5300 (17'-5'') 5135 (16'-10'') 5550 (18'-3'')
C1 Machine width 2250 (86) 2465 (97)
C2 Skip width 2090 (82) 2275 (90)
C3 Rollbar width 1520 (60)
D Track 1810 (71) 1920 (76)
E Wheelbase 2485 (98) 2700 (8'-10'')
F Ground clearance 369 (15) 406 (16)
G1 Tilt-out reach 505 (20) 490 (19) 480 (19)
G2 Tail-end lateral projection 1190 (47)
H1 Height of dump edge of skip (skip not tilted out) 1725 (68) 1730 (68) 1805 (71)
H2 Height of upper edge of skip (skip not tilted out) 2075 (82) 2305 (91)
H3 Height of dump edge of skip (skip tilted out) 1080 (43) 1175 (463) 1170 (46)
H4 Height of upper edge of skip (skip tilted out) 3525 (11'-7'') 3865 (12'-8'')
K1 Tilt angle 48° 40°
K2 Angle of rotation 90°
K3 Lateral tilt-out reach 115 (5) 100 (4) 190 (7)
