6-4 BA E16 en* 1.0 * E16_10_600.fm
6 Transportation
Drive onto a transport vehicle
1. – see chapter “ Transportation” on page 2-15
2. Secure the transport vehicle with chocks to prevent it from rolling.
3. Install access ramps at the smallest possible angle. Do not exceed an
angle of 15°.
4. Use access ramps and transport surfaces with an anti-skid surface
only.
5. Ensure that the loading area is clear and access to it is not obstructed,
for example by superstructures.
6. Start the engine.
7. Raise the boom and the stabilizer blade to avoid touching the access
ramps.
8. Carefully drive the vehicle onto the middle of the transport vehicle.
9. Move the vehicle to transport position:
- Position the boom straight ahead at the center of the vehicle.
- Lower the boom and the stabilizer blade.
10.Stop the engine.
11.Raise the control lever base.
12.Remove the starting key and carry it with you.
13.Leave the cabin, close and lock all doors, windows and covers.
14.Firmly fasten the vehicle on the loading area with tie-downs A and B
with slings C of appropriate size. Observe legal rules and regulations.
