Maintenance 7
7.3 Consumables
Application Fluid/lubricant Specification
Season/
Temperature
Capacities
1
1. The capacities indicated are approximate values; the oil level check alone is relevant for the correct oil level.
Capacities indicated are no system fills
Engine
Diesel fuel
2, 3
2. 3TNV88-BPWN: In regions without exhaust gas regulations the engine may be operated with a sulfur content of up to 0.5% (= 5000 ppm).
3. 3TNV88F-EPWN: In regions without exhaust gas regulations the engine may be operated with a sulfur content of up to 0.1% (= 1000 ppm).
EN 590 (EU)
4
4. Sulfur content up to 0.0010% (= 10 ppm)
Year-round
5
5. Summer or winter diesel depending on outside temperatures
44 liters
(11.6 gal)
ASTM D975 grade 1D S15
ASTM D975 grade 2D S15
(USA)
6
6. Sulfur content up to 0.0015% (= 15 ppm)
BS 2869 class A1
BS 2869 class A2 (GB)
7
7. Sulfur content up to 0.001% (= 10 ppm)
GB252 (China)
8
8. GB 20891-2014: Sulfur content up to 0.035% (= 350 ppm)
Coolant
9
9. Mixing ratio 50:50
Distilled water and anti-
freeze ASTM D6210
Year-round
5 liters
(1.3 gal)
10
10. System fills incl. hoses and diesel engine
Engine oil
11
11. Viscosity SAE 10W40 according to DIN 51511; For other temperatures – see chapter “ Engine oil types” on page 7-19
API: CF/CF-4/CI-4
ACEA: E3/E4/5
JASO: DH-1
-20°C (-4 °F) to
+40°C (+104 °F)
12
12. Temperature guide values are dependent on the oil manufacturer
6.7 liters
(1.8 gal)
Hydraulic oil reser-
voir
Hydraulic oil Eurolub HVLP 46
13
13. According to DIN 51524 section 3, ISO-VG 46
Year-round
14
14. Depending on local conditions – see chapter “ Hydraulic oil types” on page 7-18
61.5 liters
(16.3 gal)
Biodegradable
hydraulic oil
15
15. Biodegradable hydraulic oil based on saturated synthetic esters with an iodine value of < 10, according to DIN 51524, section 3, HVLP, HEES
Panolin HLP Synth 46
BP Biohyd SE-S 46
Washer system Cleaning agent
Glass cleaner and anti-
freeze
Year-round
1 liters
(0.3 gal)
Grease nipples Grease
KPF 2 K-20
16
ISO-L-X-BCEB 2
17
16. KPF 2 K-20 according to DIN 51502 lithium-saponified grease
17. ISO-L-X-BCEB 2 according to DIN ISO 6743-9, lithium-saponified grease
Year-round As required
Battery terminals Acid-proof grease
18
18. Standard acid-proof grease NGLI category 2
FINA Marson L2 Year-round As required
Control lever base Adhesive fluid grease Förch S401 Year-round As required
