BA E16 en* 1.0 * E16_10_710.fm 7-43
Maintenance 7
Adding hydraulic oil
Slipping/tripping hazard when adding hydraulic oil!
Can cause injury.
► Use a safety-oriented ladder to add hydraulic oil.
► Do not use vehicle parts or attachments as a climbing aid.
1. Open reservoir ventilation B to release the pressure.
2. Open cover C slowly to release the pressure inside the hydraulic oil
tank.
3. Remove cover C.
4. Add hydraulic oil up to the corresponding mark.
5. Check the hydraulic oil level on sight glass A.
6. Add if necessary and check again.
7. Screw in cover C tightly.
Use a suitable container to collect fluids and lubricants as they flow out
and dispose of them in an environmentally friendly manner.
