7-48 BA E16 en* 1.0 * E16_10_710.fm
7 Maintenance
Steel track (option)
Place a measuring rod B across the highest points of the track.
• Adjust the track tension if play C between the track roller and the track
is not 20 - 25 mm (0.8 - 1 in).
Correcting track tension
Injury hazard due to grease escaping under pressure!
Grease escaping under pressure can penetrate the skin and cause
serious injury or death.
► Open the lubricating valve only very carefully and do not unscrew it
more than one revolution.
► Wear protective equipment.
► Contact a Wacker Neuson service center if you are unable to reduce
the track tension.
Possible damage to cylinders and tracks due to over-tightening.
► Tighten the tracks only up to the mandatory measuring distance.
