9 Technical data
B
Fuse Ampere Relays Tier III
F001 40
K005, K007,
K009
Pre-heat, starting relay, cut-off solenoid relay
F002 50 -- Ignition lock
F003 10 K008 Cut-off solenoid time lag relay, flow pump, indicating instrument
F004 10 -- Boom light, rear roof light
F005 10 -- Front roof lights
F006 10 K058
Speed 2, valves, horn, proportional auxiliary hydraulics (AUXI),
3rd control circuit proportional (AUX II)
F007 20 K051
Heating, air conditioning, driving signal, automatic speed control time
lag relay
F008 10 -- Interior light, wiper
F009 5 -- Machine control unit
F010 15 -- 12 V connection, rotating beacon, radio
F011 10 -- Machine control unit (VDS/HSWS)
Fuse Ampere Relays Tier IV
F001 40 K005, K007 Pre-heating, starting relay
F002 50 -- Ignition lock
F003 5 K042, K061 Relay (engine), flow pump, start lock switching relay
F004 5 -- Control elements, display, drive signal
F005 10 -- Boom light, rear roof light
F006 10 -- Front roof lights
F007 10 K130 Horn, interior light, window wiper
F008 5 -- Machine control unit
F009 10 -- Cigarette lighter, rotating beacon, radio
F010 15 -- 12 V connection
F011 10 K001 Engine control unit, main relay (engine)
F012 20 -- Machine control unit
F013 20 -- Heating, air conditioning
V1 -- -- Diode
-- -- only for authorized service center
