BA E16 en* 1.0 * E16_10_900.fm 9-41
Technical data 9
ET35
Base travel gear
dimensions
mm (in)
VDS
dimensions
mm (in)
A1 Height with rotating beacon 2630 (8‘-8“) 2711 (8‘-11“)
A2 Height 2491 (8-2“) 2573 (8‘-5“)
B1 Cabin width 980 (39) 980 (39)
B2 Upper carriage width 1630 (64) 1630 (64)
B3 Travel gear width 1630 (64) 1630 (64)
B4 Stabilizer blade width 1630 (64) 1630 (64)
B5 Dozer blade width (swiveling) 1474 (58) --
C1 Transport length with stabilizer blade (short stick) 5268 (17‘-3“) 5252 (17‘-3“)
C2 Transport length with stabilizer blade (long stick) 5268 (17‘-3“) 5271 (17‘-4“)
C3 Transport length without dozer blade (long stick) 4773 (15‘-8“) 4780 (15‘-8“)
D1 Max. digging depth (short stick) 3245 (10‘-8“) 3166 (10‘-5“)
D2 Max. digging depth (long stick) 3497 (11‘-6“) 3416 (11‘-2“)
E1 Max. vertical digging depth (short stick) 2120 (83) 2042 (80)
E2 Max. vertical digging depth (long stick) 2360 (93) 2279 (90)
F1 Max. digging height (short stick) 4929 (16‘-2“) 5010 (16‘-5“)
F2 Max. digging height (long stick) 5082 (16‘-8“) 5163 (16‘-11“)
G1 Max. tilt-out height (short stick) 3337 (10‘-11“) 3417 (11‘-3“)
G2 Max. tilt-out height (long stick) 3489 (11‘-5“) 3570 (11‘-9“)
H1 Max. reach at ground level (short stick) 5158 (16‘-11“) 5143 (16‘-10“)
H2 Max. reach at ground level (long stick) 5408 (17‘-9“) 5393 (17‘-8“)
K1 Max. digging radius (short stick) 5270 (17‘-3“) 5270 (17‘-3“)
K2 Max. digging radius (long stick) 5507 (18‘-1“) 5507 (18‘-1“)
M Max. boom displacement to bucket center (right side) 476 (19) 476 (19)
N Max. boom displacement to bucket center (left side) 447 (18) 447 (18)
O Max. lift height of stabilizer blade over ground 393 (15) 393 (15)
P Max. scraping depth of stabilizer blade below ground surface 505 (20) 505 (20)
Q1 Distance between bucket and stabilizer blade (short stick) 135 (5) 135 (5)
Q2 Distance between bucket and stabilizer blade (long stick) 15 (0.6) 15 (0.6)
R1 Min. tail end swiveling radius 1168 (46) 1168 (46)
R1H Min. tail end swiveling radius with additional weight 1260 (50) 1260 (50)
R2 Boom swivel radius (center) 2008 (79) 2008 (79)
R3 Boom swivel radius (right) 1870 (74) 1870 (74)
R4 Boom swivel radius (left) 1725 (68) 1725 (68)
S Total running gear length 2062 (81) 2062 (81)
T Running gear length (Turas front idler) 1604 (63) 1604 (63)
V VDS tilt angle -- 15°
W1 Max. tilting angle of boom to the right 55° 55°
W2 Max. tilting angle of boom to the left 70° 70°
W3 Max. swivel angle of the dozer blade (swiveling) 25° --
X Track width 300 (12) 300 (12)
Z Stabilizer blade height 357 (14) 357 (14)
