Wacker Neuson E16-02 User Manual

BA E16 en* 1.0 * E16_10_300.fm 3-9
Introduction 3
Meaning
Crush Hazard
All persons must stay clear of a raised load or of the danger zone.
Position
On the left and right side on the lifting arm.
Meaning
Crush Hazard
Do not allow anyone to stay in the danger zone of the vehicle.
Position
At the front left and right of the chassis
Meaning
Explosion hazard due to wrong connection of battery jump cables
Position
Next to the battery
Meaning
Crush Hazard
Do not allow anyone to stay in the swiveling range of the vehicle.
Position
On the rear left of the cabin
Meaning
Crush Hazard
Do not allow anyone to stay in the swiveling range of the vehicle.
Position
At the additional weight on the left and right of the vehicle
Meaning
Modifications to the structure (for example welding, drilling), retrofitting,
and incorrect repairs affect the protective effect of the cabin and can
cause serious injury and even death.
Position
On the rear left of the cabin
Fig. 10
Fig. 11
Fig. 12
Fig. 13
Fig. 14
Fig. 15

Wacker Neuson E16-02 Specifications

General

Brand	Wacker Neuson
Model	E16-02
Category	Excavators
Language	English
