BA E16 en* 1.0 * E16_10_400.fm 4-5
Putting into operation 4
Opening the lower front window
Press levers A on the left and right, and pull the front window upward with
handles B on the left and right until the front window engages with guide
C.
Closing the lower front window
Keep levers A pressed on the left and right, and pull the lower front
window downward with handles B on the left and right until the front
window locks into place.
Fig. 78
Fig. 79
B
A
C
Fig. 80
A
B
