22
Description EHB 11
Supplementary handle
The Pro-Ergo
®
supplementary handle can be adjusted to various positions to en-
sure safe working conditions and reduce operator fatigue. The offset and the ra-
dial handle are part of the supplementary handle.
Adjustment options:
The entire supplemental handle can be swiveled variably by 360°.
The offset handle can be turned by approx. 270° in increments of 22.5° (not
present on all machines).
The radial handle can be screwed to the supplementary handle or housing
sides.
Adjustable depth gauge
The depth gauge enables the variable adjustment of the drilling depth.
Item Designation
1 Offset handle (not present on all
machines)
2 Radial handle
3 Clamping wheel (not present on
all machines)
4 Clamping piece
