EHB 11 Operation
33
7.3.3 Tool holder for tool with hexagonal bolt
Inserting tool
1. Clean tool end.
2. Swivel out retaining spring.
3. Push tool into the tool holder as far as it will go.
4. Return retaining spring to original position.
5. Check to see if the tool is locked by pulling on the tool.
Removing tool
1. Swivel out retaining spring.
2. Remove tool from the tool holder.
3. Return retaining spring to original position.
Item Designation
1Tool
2 Retaining spring
