5-32 BA E16 en* 1.0 * E16_10_510.fm
5 Operation
Proportional control tier IV
Example for AUX I. The operation for AUX II, AUX III and the dozer blade
are identical.
Performing the adjustments
• Press push button C to call the settings.
• The settings are selected (turn) and confirmed (press) with adjustment
button A.
Push button B (return) takes you back to the previous menu level.
Control circuit Attachments Starting point Flow rate
A
B C
