4 Putting into operation
4.3 Indicator lights and warning lights (overview)
Display element/multifunctional display
1
The display element and the multi-functional display inform the operator
about operating states, required maintenance procedures and possible
vehicle malfunctions.
It may take a few seconds before a selected function is displayed.
The indicator lights are tested when the starter is engaged and are
illuminated for a few seconds.
1. The assignment of the indicator lights can vary depending on the equipment.
Fig. 108 Display element tier IV
5
8
13
12
10
11
2
3
4
9
14 16 15
Fig. 108 Display element tier III
38373635
34
40 4139 43 4442
46 4745 49 5048
31
32 33
6
7
1
