4-30 BA E16 en* 1.0 * E16_10_400.fm
4 Putting into operation
The graphic symbols shown may deviate.
-- 35 Blue Not assigned --
-- 36 Green Not assigned --
-- 38 Red General vehicle malfunction 8-1
-- 41 Yellow Engine warning 8-1
-- 42 Red Engine stop 8-1
-- 43 -- Not assigned --
-- 44 -- Not assigned --
-- 46 -- -- Not assigned --
-- 47 -- -- Not assigned --
--
48
Red Hydraulic functions locked 4-39
-- Red Hydraulic functions active 4-39
-- 49 -- Additional control circuit AUX II (option) 5-30
-- 50 -- Not assigned --
Tier III Tier IV Symbol Color Designation
