Wacker Neuson GP 2500A

Maintenance GP 2500A
wc_tx000448gb.fm 34
6.12 Wire Colors
6.13 Wiring Schematic
See Graphic: wc_gr002325
Wire Colors
B Black R Red Y Yellow Or Orange
G Green T Tan Br Brown Pr Purple
L Blue V Violet Cl Clear Sh Shield
P Pink W White Gr Gray LL Light blue
Ref. Description Ref. Description Ref. Description
A Generator B Control Box C Engine
Ref. Description Ref. Description
1 Main stator winding 7 Duplex receptacle—120V
2 Secondary winding 8 Ignition switch
3 Rotor winding 9 Oil alert module
4 Automatic voltage regulator 10 Oil level switch
5 20A circuit breaker 11 Coil
6 GFI duplex receptacle—120V
