Wacker Neuson GP 6600A

Operation GP/GPS 6600A
28 wc_tx000792gb.fm
3.10 Control Panel
Ref. Description Ref. Description
a Engine Switch g GFCI test button
bAuto Idle Switch h GFCI reset button
c Twist-lock receptacle - 120V j Twist-lock receptacle - 120/240V
d Main Circuit Breaker k Ignition Switch (GPS only)
e Voltage Selector Switch m 20A circuit breaker (CAN only)
f Duplex receptacle - 120V n 30A circuit breaker (CAN only)
wc_gr003143
