GPS 8500 / GPS 9700 Maintenance
39
Ref. Description Ref. Description Ref. Description
A Generator B Control box C Engine
Ref. Description Ref. Description
1 Main stator winding 10 Choke
2 Transformer 11 Hour meter
3 Auto Voltage Regulator (AVR) 12 Engine module
4 Resistor (GPS 9700 only) 13 Oil level switch
5 Rotor winding 14 Coil
6 Circuit breaker 15 Starter
7 Auto idle unit 16 Battery
8 Auto idle switch 17 Voltage selector switch (VSS)
9 Auxiliary stator winding 18 Terminal block
