Control Panel (G 3.7A, G 5.6A and GS 5.6A Models)
Ref. Description Ref. Description
a Engine Switch (GS 5.6A only) f GFI Duplex receptacle - 120V
b Auto Idle Switch g GFI test button
c Twist-lock receptacle - 240V h GFI reset button
d Main Breaker j Twist-lock receptacle - 120V
e Voltage Selector Switch
