Disassembly & Assembly RD 12/RD 12A
wc_tx000671gb.fm 104
9.27 Removing the Engine
Prerequisites Crane and appropriate sling
Exciter pump and drive pump removed
Procedure Follow the procedure below to remove the engine.
1. Disconnect the harness (a) and the wiring (b).
2. Disconnect the exhaust (c) and the choke cable (d).
3. Cut the wire ties that secure the oil drain hose (e).
4. Disconnect the fuel line (f).
This procedure continues on the next page.
Burn hazard. The engine exhaust pipes are extremely hot while the engine is run-
ning and for a period of time after the engine has shut down.
f Allow the exhaust pipes to cool before performing this procedure.
wc_gr004173
a
b
c
d
wc_gr004174
e
c
f
To Next Page
