Drive System RD 12/RD 12A
wc_tx000667gb.fm 54
Continued from the previous page.
5. Secure the drum support with an appropriate crane and sling (e).
6. Remove the screws that secure the drum support and remove the drum support.
7. Rotate the drive plate (f) by hand and make sure the motor turns freely.
The drive motor has now been checked for binding.
wc_gr004127
e
f
