MOVEMENT AND MARCH:
MOVEMENT
Traversing of the machine is controlled by the left joy-stick. The various joy-stick positions, de-
pending on the manoeuvre to be carried out, are represented below.
STRAIGHT LINE MOVEMENT
Position A: FORWARD movement
Position B: REVERSE movement (an acoustic safety device is activated)
CHANGEOF DIRECTION
PositionF: 90°RIGHTTURN
Page 21 of 61
Item – Rev(s): 8009641121– 101
