7
Product specifications
STU-540 / STU-541
General Specifications
Dimensions (W x D x H) 162.8 x 156.8 x 10.0 mm
Weight Main Body: 250 g approximate
Operating temperature & humidity
5 to 40 degrees C, humidity: 30% to 80% RH
(non-condensing)
Storage temperature & humidity
-20 to 60 degree C, humidity: 30% to 90% RH
(non-condensing)
Interface cable USB cable specialized for Corvina, length 3m
Power consumption 2.5 W maximum
Display
Display panel Amorphous-TFT-LCD
Screen size 5.0 inch (108.8 x 64.8 mm)
Number of pixels 800 x 480, WVGA
Pixel pitch 0.135 (H) x 0.135 (V) mm
Viewing Angle 140(70/70) / 140(70/70) as CR>=10 condition
Luminance Typ. 160 cd/m
2
LCD quality Each LCD panel is produced under very
stringent quality standards. Production
techniques cannot guarantee an absolutely
perfect TFT display. Wacom does not allow
any pixel to be always white or always black.
A small number of pixels are allowed to show
a wrong color for some parts of the color
spectrum. This does not mean the display is
defective.
Pen tablet
Reading technology Electro-magnetic resonance technology
Active area 108.0 x 64.8 mm
Resolution 2540 lpi or 0.01 mm/pt
Accuracy ± 0.5 mm (center), the edge area 1 (20mm
wide from edge of display area) to be
±2.0mm, the edge area 2 (3 mm wide from
edge of display area) to be ± 4.0 mm
Reading height 5 mm or more (center)
Maximum report rate 200 points/sec
Pressure levels 1024 levels
Communication interface STU-540: USB, VCP, RS232
STU-541: USB, VCP
Others
Security slot 1
Pen
Physical size (L * D) 141.5 * 9.0 mm (5.57 * 0.35 in)
Weight 7 g (0.25 oz), approximately
RS232 connection interface kit (Optional accessory)
Model name Serial kit for STU-540
Part number ACK-422-01-ZX
Connector type D-sub 9pin
Power supply AC adaptor (Maker: Asian Power Devices INC. ,
Model number:WB-10E05R)
