Tips for use.
When working on lying objects: Turn the suction tube forwards. (Fig. 5 A)
•
Spraying work when working on overhead objects: Turn the suction tube rearwards.
(Fig. 5 B)
Attention! Only hold the handle extension at the grips provided when
the unit is switched on. Touching the tension cable can accidentally
trigger the gun.
You will nd further information on spraying technique, regulation of
material and air ow and also general information in the Operating
Instructions for the basic unit.
Taking Out of Operation and Cleaning
Proper cleaning is the prerequisite for problem-free operation of the paint application
device. No warranty claims are accepted in case of improper or no cleaning.
Turn o the machine and remove the plug. 1)
Press the hook (Fig. 2 "click") slightly downwards. Remove the front section of the
2)
gun.
Remove the handle extension from the gun handle in the same way. 3)
Attention! The handle extension is only solvent resistant to a limited
extent.
Do not immerse in solvent, only wipe.
Remove the handle extension and if required wipe it with a cloth soaked with water 4)
or solvent.
To clean the front section of the gun please follow the instructions in
the Operating Instructions for the basic unit.
For easier assembly of the components after cleaning please apply
lubricating grease (enclosed) to the O-rings on the front section of the
gun and the handle extension
Spare Parts List (Fig. 6)
Pos. Designation Order No.
1 Rear section 2307 503
2 Front Section 2307 505
3 Spring 0417 316
Lubricating grease 9892 550
The new CLICK&PAINT SYSTEM with additional spray attachments and accessories
oers the right tool for each work.
