15. Spare Parts List
Spare Parts List (Fig. 10)
Pos. Designation Order No.
1 Union nut 2362 873
2 Air cap 2362 877
3 Nozzle 2362 878
4 Nozzle seal 0417 706
5 O-ring 2362 875
6 Material volume regulation with spring, complete 0417 910
7 Spray gun front part complete incl. 800 ml container 2361 730
8 Air lter set 0417 912
9 Air lter cover (right + left) 2362 874
10 Container seal 2323 039
11 Suction tube 2362 876
12 Container with cover 0413 909
13,14,15 Ventilating hose, valve cover, diaphragm 2304 027
16 Stir stick 2304 419
17 Lubricating grease (no g.) 2315 539
16. Accessories
The CLICK&PAINT SYSTEM with additional spray attachments and accessories oers
the right tool for each work.
i
We recommend against using the W 100 with the Wall Extra I-Spray
spray attachment.
Further information about the WAGNER range of products for renovating is
available under www.wagner-group.com
17. Correction of Malfunctions
Problem Cause Remedy
No coating
material
emerges from
the nozzle
•
Nozzle clogged
•
Feed tube clogged
•
Material volume setting turned
too far to the left (-)
•
Feed tube loose
•
No pressure build-up in container
➞ Clean
➞ Clean
➞ Turn to the right (+)
Insert
➞ Tighten container
