WAGNER W 180 P

Adjusting the spray tip
1. Make sure the spray gun is unplugged.
2. Loosen the tip by turning the tip counter clockwise.
3. Turn the adjusting arm so that it is pointing down for a horizontal
pattern.
4. Turn the adjusting arm so that it is pointing to the side for a vertical
pattern.
5. Tighten the tip firmly by hand.
