WAGNER W 180 P User Manual

16
W 180 P
GB
7, arrow). Briey switch on the spray gun.
i
The spray gun can only operate satisfactorily if it is cleaned and preserved
after each use.
Accessories W 180 P (not included in scope of delivery)
Designation Order No.
Paint container with cover 0413 909
Needle-jet nozzle 0209 045
Flexible nozzle extension with atomiser
For spraying ceilings, resting objects or hard-to-reach areas e.g. radiators 0046 675
Spare Parts List (Illus. 9)
Pos Name Order No.
1 Suction tube 0413 305
2 Paint container with cover 0413 909
3 Nozzle 0,8 mm 0046 903
4 Locking nut 0413 310
5 Valve 0209 042
6 Pump housing 0413 202
7 Piston spring 0033 028
8 Piston 0198 207
9 Nozzle spanner 0199 327
10 Viscosity measuring cup 0209 058
Correction of Malfunctions
Problem Cause Remedy
Spray gun buzzes
and does not work
•
Piston stuck
•
Defective drive
➞ Disassemble pump and
clean with thinner
➞ Please contact Wagner
Service
Spray gun does not
suck in
•
No valve in the pump
•
Suction tube loose in the
conical bore
•
Venting hole in pump housing
clogged
•
Intake hole (tting) in
pumphousing logged
•
Viscosity of spray material too
high
➞ Insert valve
➞ Adjust suction tube
➞ Clean
➞ Clean
➞ Thin accordingly
