GB
4
Start-up
Before connecting to the mains supply, be sure that the supply voltage is identical with
the value given on the rating plate.
● Attach carrying belt to machine (Fig.3)
● Mounting air hose. Insert the air hose tightly in the connections on the machine
and the spray gun (Fig. 4, a + b). The connections can be positioned as desired.
● Mount spray gun holder. (Fig. 5)
● Unscrew the container from the spray gun.
● Aligning suction tube (Fig. 6)
The container contents are to be sprayed out almost completely.
When spraying horizontal surfaces, turn suction tube forward (A).
When spraying objects overhead, turn suction tube back (B).
● Set the container on a sheet of paper, pour in the prepared coating material and
screw the container tightly onto the spray gun.
● Place the spray gun in the gun holder on the machine (Fig. 7).
● Put the machine down only on a level, clean surface. Otherwise the machine could
suck in dust, etc.
● Hang the machine on your shoulder with the carrying belt.
● Take the spray gun out of the spray gun holder and point it at the target object.
● Push the ON / OFF switch on the machine.
● Adjust the spray setting on the spray gun.
Three different spray jet settings can be chosen on the spray gun, depending on
the application and target object.
Selecting the Spray Setting
Fig. 8 A = horizontal flat jet ➟ for horizontal surfaces
Fig. 8 B = vertical flat jet ➟ for vertical surfaces
Fig. 8 C = circular jet ➟ for corners, edges and hard-to-reach
surfaces
Adjusting the desired Spray Setting (Fig. 9)
With the union nut (2) slightly tightened, turn the air cap (1) to the desired spray-setting
position (arrow).
WARNING! Danger of injury! Never pull the trigger guard while
adjusting the air cap.
W 640
