WAGNER W 95 Manual

16
W 95
GB
Spare Parts List (Illus. 8)
Pos Name Order No.
1 Suction tube 0413 305
2 Paint container with cover 0414 906
3 Nozzle 0,8 mm 0046 903
4 Locking nut 0413 310
5 Valve 0209 042
6, 7, 8 Pump housing, Piston spring, Piston 0402 704
9 Nozzle spanner 0199 327
10 Viscosity measuring cup 0209 058
Correction of Malfunctions
Problem Cause Remedy
Spray gun
buzzes and
does not work
•
Piston stuck
•
Defective drive
➞ Disassemble pump and
clean with thinner
➞ Please contact Wagner
Service
Spray gun
does not suck
in
•
No valve in the pump
•
Suction tube loose in the conical
bore
•
Venting hole in pump housing
clogged
•
Intake hole (tting) in
pumphousing logged
•
Viscosity of spray material too high
➞ Insert valve
➞ Adjust suction tube
➞ Clean
➞ Clean
➞ Thin accordingly
Spray gun
sucks in but
does not spray
•
Nozzle clogged
•
Ducts and holes in atomiser clogged
➞ Clean
➞ Clean
Spray gun
works but
sprays
unevenly
•
Spray material in container
running out
•
Spray gun held inclined leading to
sucking in of air
•
Viscosity of spray material too high
(too thick)
•
Fine adjustment button not set
correctly
•
Nozzle worn out
•
Valve worn out
•
Wrong valve inserted
➞ Rell
➞ Use exible nozzle
extension (see accessories)
➞ Dilute accordingly
➞ Reset according to spray
material
➞ Replace
➞ Replace
➞ Use correct valve
