Attention! Never operate the device if the nozzle seal is either damaged or
missing. If the nozzle seal is either missing or damaged liquids can enter
the device and increase the risk of an electric shock.
Slide the nozzle seal (Item 4) with the groove (slot) facing forwards into the nozzle
(Fig. 10 B). Put the nozzle onto the gun body and nd the correct position by turning it.
Put the air cap onto the nozzle and tighten it using the union nut.
Place the container seal from below on the suction tube and slide it over the collar, while
turning the container seal slightly. Insert the suction tube with container seal in the gun
body.
14. Maintenance
WARNING! Never operate the machine without the air lter; dirt could be
sucked in and interfere with the function of the machine. Disconnect plug
before changing parts.
Change the air lter if it is soiled (Fig. 9).
•
In order to mount the gun more easily apply lubricating grease (enclosed) liberally
•
to the O-ring at the gun front part. (Fig. 10, Item 5)
15. Spare Parts List
Spare Parts List (Fig. 10)
Pos. Designation Order No.
1 Union nut 0417 319
2 Air cap 2305 129
3 Nozzle (2.5 mm) 2305 131
4 Nozzle seal 0417 706
5 O-ring 0417 308
6 Material volume regulation with spring, complete 0417 910
7 Spray gun front part complete incl. 800 ml container 0417 914
8 Air lter set 0417 912
9 Air lter cover (right + left) 0417 303
10 Container seal 0417 358
11 Suction tube 0417 357
12 Container with cover 0413 909
13,14,15 Ventilating hose, valve cover, diaphragm 2304 027
16 Stir stick 2304 419
17 Lubricating grease (no g.) 2315 539
