29
Description of parts (Fig. 1)
A. Blade set
B. On/o󰀨switch
C. Charging indicator
D. Charging stand
E. Charging stand socket
F. Oil for blade set
G. Cleaning brush
H. Attachment comb
I. Plug-in transformer
J. Appliance plug
*Beforetheapplianceisusedforthersttimeitshouldbechargedfor16 hours.
ChargingtheRechargeableBattery
1. Connect the appliance plug (J) on the plug-in transformer to the charging stand socket (E) (Fig. 2a).
Battery overcharging is prevented thanks to intelligent charge management.
2. Connect the plug-in transformer to the mains socket (Fig. 2a).
3. Switcho󰀨theapplianceusingtheon/o󰀨switch(Fig.3a).
4. Place the appliance on the charging station (Fig. 2) · During charging, the charging indicator (C) is
illuminated.
• After the appliance has been removed from the charging stand, the display goes out.
• It takes no more than 16 hours for the appliance to charge to full capacity.
BatteryOperation
1. Switchontheapplianceusingtheon/o󰀨switchandswitcho󰀨afteruse(Fig.3a/b).
• With the battery fully charged, the appliance can be operated for up to 100 minutes. This
capacityisattainedafterapprox.5-10chargingcycles.Incaseofinsu󰀩cientmaintenanceof
the blade set, the operating time can be reduced considerably.
OPERATION
Cutting with the attachment comb
The appliance can also be operated with an attachment comb. The attachment comb has 5 indent
positionsforadjustingthelengthofcutThefurthertheattachmentcombispushedin(retracted),the
shorterthelengthofcut.Thelengthofcutcanbeadjustedfrom3mm(Fig.5a)to6mm(Fig.5b).
Attachment Comb
Attaching/removing the attachment comb
1. Slide the attachment comb on to the blade set in the direction of the arrow until it reaches the limit
stop (Fig. 4a).
2. The attachment comb can be removed by pushing it in the direction of the arrow (g4b)
If the cutting performance deteriorates after long use despite regular cleaning and oiling, the blade set
should be replaced.
Changing the blade set
Removing the blade set:
1. Switchtheapplianceo󰀨usingtheon/o󰀨switch(Fig.3a)anddisconnectfromthepowersupply.
2. Slidethebladeseto󰀨thehousinginthedirectionofthearrow(Fig.6a).Removethebladeset.
Replacing the blade set:
1. Replace the blade set by hooking it into the housing. The small lug at the base of the blade should
be aligned with the indent on the clipper casing. Press the blade down until it clicks into position
(Fig. 6b).
BatteryRemoval,DisposalandReplacement
For removal instructions see page 33
Model: BRAVMINI RECHARGEABLE DOG TRIMMER - WM6590
