Model: MAX 45 CORDED DOG CLIPPER - KM6245 / WM6245
Description of parts (Fig. 1)
A. Blade set
B. Release button for blade set
C. On/o󰀨switch
D. Airlter
E. Hang-up loop
F. Mains cable
G. Oil for blade set
H. Cleaning brush
Mains Operation
1. Connect to the mains power supply (Fig. 2)
2. Switchontheapplianceusingtheon/o󰀨switchandswitcho󰀨afteruse(Fig.3).
The appliance has two speed settings.
Thesecanbeselectedviatheon/o󰀨switch.
Setting I = slow speed
Setting II = high speed
Cutting with the attachment comb
The appliance can also be operated with attachment combs. Attachment combs can be used to extend
the cutting length range.
For best results we recommend using a #30 or #10 blade with the comb attachments.
Accessories are available from your local dealer.
Attaching / removing the attachment comb
1. Fit the attachment comb onto the bottom edge of the blade set (Fig. 4a) and push it over the cutting
edge of the bottom blade until it locks (Fig. 4b).
2. Push the attachment comb towards the cutting edge of the bottom blade (Fig. 5) and remove it from
the blade set.
Changing the blade set
To remove a blade set:
1. Switcho󰀨theapplianceusingtheon/o󰀨switch(Fig.3).
2. Press the release button (B) (Fig. 6a) towards the blade set and lift the blade set away from the
housing (Fig. 6b).
3. Remove the blade set from the clip (Fig. 6c).
To attach a new blade set:
1. Attach the new blade set onto the clip (Fig. 8a).
2. Ensurethattheclipisfoldedout.Ifthisisnotthecase,youcanfoldouttheclipwithaat
screwdriver (Fig. 7).
3. Push the blade towards the machine to snap into place.
4. If the blade fails to engage, switch the appliance on (Fig. 3), then push the blade set against the
hand-held appliance until it audibly clicks into place and the blade moves (Fig. 8b).
Remove the attachment comb (Fig. 5) after every use and lift the blade set out of the casing (Fig. 6).
Use the cleaning brush to remove any cut hairs from the housing opening and from the blade set (Fig. 9).
Caution! Injuriesduetoincorrecthandling.
Thebladesetmustnotbeunscrewed.Thetopblademustnotbepushedoutcompletely!
• Push the top blade to the side (Fig. 9a) and remove cut hairs from the top and bottom blade using
the cleaning brush.
• After cleaning, return the top blade to its initial position (Fig. 9b). The top blade should be aligned in
the centre of the bottom blade. After cleaning the blade set, we recommend using hygienic spray.
Itkeepsallbladesetshygienicallycleanandise󰀨ectiveagainstbacteriaandviruses.
