Mounting
ENG
3. Mounting
CAUTION
Risk of injury caused b
y a f
alling lumi-
nair
e.
P
ersonal injur
y and material damage.
X Use only suitable fastening ele-
ments available from the manuf
ac-
turer.
X Mount fastening elements cor-
rectly.
3.1 Dimensions
a
c
b
No. Luminaire Dimension
a
MFA 320/750
190 mm
MFA 780/750 365 mm
MFA 1250/750 540 mm
MFA 1670/750 715 mm
b
all
30 mm
c
all
40 mm
Tab. 2: Dimensions.
3.2 Mounting the luminaire
NOTE: For this luminaire, fastening ele-
ments are av
ailable as accessories. For
more information, please visit our home-
page www.waldmann.com.
X Mount the luminaire using suitable fas-
tening elements to the mounting sur-
face. To do so, use the dimensions of
the luminaire, see Tab. 2.
