14 15
locks. The same applies to adjusting the boom with mounted equipment
and /or counterweight.
■ When attaching equipment via 1/4 inch thread, please note that these
have a lower load capacity than the 16 mm spigot (5/8 inch spigot)
connection. For mounting heavier equipment, an appropriately high quali-
ty bracket is required.
■ Do not move an equipped stand with the centre column extended and /or
the boom attached, or only move it very carefully and very low above the
ground. There is often an unexpectedly strong and very sudden leverage
effect with heavy equipment in combination with a large centre column
extension. Due to the design-related top-heaviness of a lamp stand with
attached equipment, especially when using the boom, the stand can tip
over in a ash and the attached equipment can be damaged and /or injure
the operator.
Technical specications
Walimex pro boom stand WT-501
Item number 12130
Type Lamp Stand with Boom
Maximum working height 410 cm
Maximum extension of the boom 215 cm
Connections on the boom 1/4 “ thread, 5/8 “ spigot
Max. Load capacity of boom 5 kg
Max. load on boom when extended 3 kg
Max. load stand 6 kg
Weight of boom and bracket 1.4 kg
Counterweight 4.4 kg
Damping of stand Spring damping
Material of stand and bracket Aluminium, metal
Scope of delivery:
1 x Walimex pro WT-501 Boom 115 - 215 cm
1 x Boom holder
1 x Weight 4,4 kg
1 x Mounting adapter
1 x Walimex pro WT-501 lamp stand with spring damping, 100 - 200 cm
