Walker Edison CMAB5C - Hardware List

Philips head screwdriver required
for assembly (not included)
P.4
The hardware quantities listed above are required for proper assembly.
Some extra hardware may also have been included.
Hardware List
C
04 pcs
D
Hex key
01 pc
E
Nut
04 pcs
ø1/4"*90mm
Bolt
B
14 pcs
ø7,0"*80mm
Bolt
A
12 pcs
ø7,0"*40mm
Bolt
F
Screw
39 pcs
J
Support
02 pcs
ø4.0*16mm
ø4.0*30mm
I
Screw
08 pcs
G
Space Block
02 pcs
K
Dowel
10 pcs
ø10*40mm
