Walker Edison CMAB5C - Page 9

04
I
ø4.0*16mm
A+D
I
I
I
I
11
10
10
10
1
1
10
11
P.9
Step 9
Step 10
I
I
Attach parts 10 to part 11 with screw A and hex key D
Attach part 11 to support with screw I
and phillips head screwdriver.
06
A
ø7,0"*40mm
01
D
A+D
A+D
A+D
A+D
A+D
A
A
D
11
