Walker Model MS (13 HP) - Component Identification

Component Identification
7
Front View and Right Side View
Deck
Caster Wheels
Deck Lift Handle
(Cutting Height Adjustment)
Transmission Control Rod
Adjustment Nut (RH)
Tilt-Up Latch
Grass Handling System
6.7 Bushel Catcher
Catcher Door
Safety Latch
Counterweight
Spring and
Protective Cover
NOTE: Control Identification
shown in Operating
Instructions section.
Deck Support Pin
and Height Adjustment
Hitch Pins
Catcher Lift/
Dump Handle
Transmission Control Rod
Adjustment Nut (LH)
Tilt-Up
Hook
Tilt-Up
Deck Handle
Anti-Scuff
Roller
Deck Support Arms
Footrest
Footrest
