Walker MT, MTL, MTEFI, MTLEFI User Manual

Operating Instructions
33
THROTTLE
BLADE CLUTCH (PTO)
Pull Up to Engage
PARKING
BRAKE
LEFT WHEEL
STEERING LEVER
Forward Position
(No Control Change)
Neutral-Park
Position
Reverse Drive
Wheel Motion
Position
RIGHT WHEEL
STEERING LEVER
The Forward Speed Control also Establishes the Neutral-Park Position of the Steering Levers
FORWARD SPEED
CONTROL LEVER (FSC)
Full Forward
Ground Speed
Position
Intermediate
Ground Speed
Position
Neutral-Park
Position
Disengaged
Position
Idle
Position
ON Position
OFF Position
CHOKE (MT & MTL)
Engaged
Position
Fast
Throttle
Position
Engaged
Position
Disengaged
Position
MTL MTEFI MT
MT, MTEFI, and MTL Operating Controls (Top View from Drivers Point of View)
