Walkera Master cp - Page 10

05
Transmitter
setup
5.2.4 Reverse switch settings
DEVO-6
Elevator Normal
Aileron Normal
Throttle Normal
Rudder Normal
Gyro Normal
Pitch Normal
DEVO-10
Elevator Normal
Aileron Normal
Throttle Normal
Rudder Normal
Gear Normal
Pitch Normal
Gyro Normal
AUX3 Normal
AUX4 Normal
AUX5 Normal
5.2.5 Throttle curve
DEVO-7
ELEV NORM
AILE NORM
THRO NORM
RUDD NORM
GEAR NORM
PITCH NORM
GRYO NORM
DEVO-12S
Elevator Normal
Aileron Normal
Throttle Normal
Rudder Normal
Gear Normal
Pitch Normal
Gyro Normal
AUX3 Normal
AUX4 Normal
AUX5 Normal
AUX6 Normal
AUX7 Normal
DEVO-8S
Elevator Normal
Aileron Normal
Throttle Normal
Rudder Normal
Gear Normal
Pitch Normal
Gyro Normal
AUX3 Normal
point
L M H
Flight mode
output
Normal Flight 0.0% 50.0% 100.0%
Stunt 1 100.0% 75.0% 100.0%
Stunt 2 100.0% 75.0% 100.0%
5.2.6 Pitch curve
point
L
Flight mode
output
Normal Flight -15%
Stunt 1 -55%
Stunt 2 -55%
5.2.6 Gyro sensor
Mode Manual
Switch MIX SW
Pos 0 75.0%
Pos 1 70.0%
Pos 2 50.0%
M H
+25% +55%
0% +55%
0% +55%
7
