G:\INSTRUCT\MULTISAN PRO\Multisan Pro Instructions 251119.docx Page 18
assembly drawing
no.
Qty nomination
Article
numb
er
assembly
lifting unit
1.0
1.0
1
1
Assembly unit complete Microboy E3
Assembly unit complete Microboy E3 pro
10525
181902
1.10/1.20 1
Container MICROBOY; complete without pump and
switching device
117620
1.120 1
O-ring 30x3 117703
1.140 1
Valve insert PE 117186
1.150 1
Lip seal 117188
1.160 1
Covering cap MICROBOY 117602
1.170 1 Check lid
117012.1
1.180 1
Cover for Check lid 117603
1.190 1
O-ring 125x8 117013
1.200 5
Sleeve 117015
1.210 1
Activated carbon filter 117016.0
1.220 1
Blind cover 117017
1.230 1
Valve ball 117189
1.270 2 Gasket ring Pg 9
117025
1.290 1
Sleeve gasket grey 117029
1.300 0,15m
Venting hose 12x2x150 long 117030
1.310 1
Angle nozzle G3/8 117031
1.320 1
Pressure hose MICROBOY 117604
1.330 2 Hose clip 20-32
117033
1.340 2
O-ring 34,52x3,53 117034
1.350 4
Rubber foot 117035
1.360 2
Countersunk 3,5x9,5 117605
1.370 1
Non return valve valve 117056
1.410 1 Lense head screw 4,8x22
117045
1.460 1
Reducing fitting G 1 ¼ 117055
1.470 1
Threaded sleeve G 1 ¼-IG-IG 117195
1.570 1
Locking device for check lid cover 117149
1.580 1
Lense head screw 3,5x13 117614
1.590 1 Rubber disc
117150
1.720 2
Hose sewer small 129011
1.730 2
Cap nut 129910
1.770 3
Lens head screw 3,9x13 207022
1.800 1
Protection cap from silicone 117406
1.810 1 Clamping piece
117044
1.820 1
O-ring 15x2 117206
1.830 1
Counternut G 3/8 117205
assembly: pump
2.0
2.0
1
1
Pump MICROBOY-E2; complete
Pump MICROBOY-pro; complete
117502
17688
2.10 1
End shield 200.040
2.20 1
Cablel failead 117040
2.30 1
Supply cable pump 117009
2.50 3
Shoulder bolt M5x130 800.078
2.60 3 Hex-nut M5
800.077
2.70 1
Stator MICROBOY 117132.1
2.80
2.80
1
1
Rotor MICROBOY
Rotor MICROBOY pro
117052.1
17682
2.90 2
Compansating disk 270029
