07/10/ 2014 Multi-San Instructions Page 19
Baugruppen Pos.-Nr.: Stückza
hl
Bezeichnung
Artikelnummer
assembly: pump
2.100 2
Ball bearing 6202 270017
(continuation)
2.110 1 Compensating disk 24x35x0,5
270018
2.120 1
Shaft seal 12x26x7 117125
2.130 1
Mechanical seal bonnet 270921
2.140 1
Mechanical seal bottom section 270021
2.160
2.160
1
1
Impeller Microboy
Impeller Microboy pro
272905
19520
2.170 1
Locking ring A12x1 270028
2.180 1 Shim ring 6/1x12
117200
2.190 2
Shim ring 6/0,5x12 117201
2.200 4
Shim ring 6/0,1x12 117202
2.210 1
Cutter 117197
2.220 1
Retaining ring S6 117006
2.230 1 Socket head srew M6x12
117005
2.240 1
Pump housing MICROBOY-E2 100.400
2.250 1
Bottom flange MICROBOY-E2 117002.1
2.280 1
O-ring 120x2,5 117007
2.290 4
Lens head screw 4,2x19 270024
2.300 1 O-ring 72x3,5
117700
2.310 1
Cutting plate 117198
2.320 3
Countersunk M4x8 117199
2.330 1
Hose nozzle, in-line G 3/8 117191
2.340 3
Clamping piece 117182
2.350 3 Socket head screwM6x8
117026
assembly:
Switch device
3.0 1
Switching deviceMICROBOY-E3; complete 117410.1
3.10 1
Switching box bonnet 117606
3.20 1
Switching box bottom section 117607
3.25 1
Circuit board MICROBOY-E2 600.250
3.30 1
Cable H05-VV-F-3G1-1,5m with male connector 117047
3.40 1
Control cable H03-VV-F-2x0,75-0,5m 117048
3.50 1 Pushbutton
117042
3.60 2
Cable fairlead d=8 117040
3.70 1
Cable fairlead d=5 117041
3.80 1
Manostat type 901.10 117024
3.90 1
Protection cap for manostat 117024.2
3.200 2
Lens head screw 2,9x6,5 117347
3.220 4
Lens head screw 3,5x13 117614
3.260 1 Capacitor
297226
