Questions, problems, missing parts? Before returning to your retailer, call our customer service department
at (866) 905 - 4107, 8:30 a.m. - 5:00 p.m. PST/11:30 a.m. - 8:00 p.m., EST, Monday - Friday.
7
Step 8
Step 9
Step 7:
Step 9:
Step 7
- Attach the Support (J) to the Bottom Frame (I) with
M8x35 Bolt & Washer (DD), M8 Washer (FF) and M8
Nut (GG).
- Repeat the same procedure for both sides.
- Completely tighten.
Step 8:
- Place the Basket (M) into the Supports (J), secure
by using the velcro straps.
- Open the Seat Assembbies (H).
- Secure the back leg to the seat with M8x78 Bolt &
Washer (AA), Plastic Washer (HH), M8 Washer (FF)
and M8 Nut (GG), as shown in picture.
- Repeat the same procedure for both 2 Chair.
- Don’t completely tighten.
Walmart Assembly Instruction
NOTE:
Do not completely tighten bolts
The M8 Bolt cover (HH), in step 1 to 12 are only for reference.
Please attach them to bolts in step 13.
until all steps are completed.
Install on level ground , Install not less than 6ft distance from any obstruction
(e.g.fence,garage,house,overhanging branches,laundry lines,electrical wires).
This swing unit is heavy, and may require two adults for safe assembly.
Mainstays Oversized Zero Gravity Swing
Vendor stock No. : MSS128059664001 / MSD128059664006 / MSD128059664044
