2.Assembling mech seal.
Spray water on the shaft as lubrication.
Place the stationary part in position and press in.
Put on the rotary part of mechanical seal.
Press in the rotary parts.
Place back all impellers, sleeves and intermediate
chambers in order.
Tighten up the stud bolt.
2
1
6
4
5
3
